Model Number: MZ-VAP1T0B/AM (bare), MZ-VAP1T0CW (with heatsink)

Form Factor: M.2 2280 (single-sided)

Interface: PCIe 5.0 x4, NVMe 2.0

Controller: Samsung Presto (5nm, 5-core ARM Cortex-R8)

NAND Flash: Samsung 236-layer V-NAND TLC (8th Gen)

DRAM Cache: 1GB LPDDR4X

Sequential Read: Up to 14,700 MB/s

Sequential Write: Up to 13,300 MB/s

Random Read (4KB): Up to 1,850K IOPS

Random Write (4KB): Up to 2,600K IOPS

pSLC Cache: ~114GB (dynamic + static)

Endurance (TBW): 600 TBW

MTBF: 1.5 million hours

Power Consumption: 7.6W (peak), 3.3mW (idle)

Operating Temperature: 0°C to 70°C

Encryption: AES 256-bit, TCG Opal 2.0, MS eDrive

Warranty: 5 years (not 3 years)

Dimensions (bare): 80.15 x 22.15 x 2.38 mm
