| Model | ROG-LOKI-850P-SFX-L-GAMING |
| Form Factor | SFX-L (Compact for SFF builds) |
| Wattage | 850W Continuous |
| Efficiency | 80 PLUS Platinum (Up to 92%) / Cybenetics Platinum |
| Modularity | Fully Modular (Individually Sleeved Cables) |
| Dimensions | 125 x 125 x 63.5 mm |
| Cooling | 120mm Axial-tech PWM Fan (ARGB-Illuminated) |
| Special Features | 0dB Technology (Silent below 40% load), Aura Sync |
| Warranty | 3 Years (Local) / 10 Years (Manufacturer Core) |
Voltage Rails & Output
| Rail | Max Current | Max Power |
|---|---|---|
| +12V | 70.8A | 850W |
| +5V | 20A | 110W |
| +3.3V | 20A | 110W |
| Combined (+3.3V & +5V) | — | 110W |
| -12V | 0.8A | 9.6W |
| +5VSB | 2.5A | 12.5W |
Connectors & Protection
| Connector Type | Quantity | Protection Features |
|---|---|---|
| 20+4 pin MB | 1 | OPP (Over Power) |
| 4+4 pin CPU | 2 | OVP (Over Voltage) |
| 16-pin PCIe 5.0 | 1 (600W 12VHPWR) | UVP (Under Voltage) |
| 6+2 pin PCIe | 3 | SCP (Short Circuit) |
| SATA Power | 6 | OCP (Over Current) |
| 4-pin Peripheral | 4 | OTP (Over Temperature) |
