Key Features

💡 Design & Aesthetics

• Full-metal cover conceals the PCB for a sleek, refined look.

• Onboard customizable RGB lighting enhances visual appeal without being over-the-top.

• White PCB with black accents offers a unique, premium appearance, especially in NZXT H-series cases.

⚡ Performance & Power Delivery

• 20+2+1 power phase design with 110A Smart Power Stages ensures stable, overclocking-ready power.

• 8-layer, 2-ounce copper PCB improves thermal performance and signal integrity.

❄️ Cooling & Thermal Management

• VRM heatsink array with thermal pads and dual PWM fans.

• Four dedicated M.2 heatsinks with thermal pads for sustained high-speed storage performance.

🖥️ Expansion & Memory

• PCIe 5.0 x16 slot for next-gen GPUs.

• One PCIe 3.0 x16 slot (x2 bandwidth) for additional expansion.

• Four DDR5 DIMM slots support speeds up to 8000+ MT/s, enabling ultra-fast multitasking and responsiveness.

📦 Storage & Connectivity

• Five M.2 slots:

  • 1 × PCIe 5.0 (2280)

  • 3 × PCIe 4.0 (2280)

  • 1 × PCIe 4.0 (2230, E-key for Wi-Fi/Bluetooth)

• Four SATA 6 Gbps ports for legacy storage.

• M.2 Quick-Release Latches simplify SSD installation without screws.

🌐 Next-Gen I/O

• Wi-Fi 7 (802.11be) and Bluetooth 5.4 for ultra-low latency wireless.

• 5GbE LAN for high-speed wired networking.

• USB 4 (40 Gbps) via dual Type-C ports on the rear I/O.

• Rear I/O includes:

  • 2 × USB 2.0

  • 3 × USB 3.2 Gen1 Type-A

  • 5 × USB 3.2 Gen2 Type-A

  • 2 × USB4 Type-C

  • Optical S/PDIF, 2 × Audio, Clear CMOS button, RJ-45

BIOS & Compatibility

• BIOS version 3.20 or later required for optimal compatibility with Ryzen 7 9800X3D.

• Users are advised to update BIOS and drivers via NZXT CAM for stability and performance.
