Key Specifications
-
Memory: 4x DDR5 slots, supporting up to 256GB; supports XMP 3.0 for easy overclocking.
-
Expansion Slots: 2x PCIe x16 (one PCIe 4.0 from CPU, one PCIe 3.0 from chipset), 1x PCIe x1.
-
Storage: 2x M.2 NVMe slots (PCIe 4.0 x4), 4x SATA III ports; supports RAID 0/1/5/10.
-
Networking: 2.5G LAN, integrated Wi-Fi 6E, and Bluetooth 5.3.
-
Audio: Realtek ALC897 codec for 7.1-channel HD audio.
-
Video Outputs: 2x HDMI 2.1 (4K@60Hz), 2x DisplayPort 1.4 (4K@60Hz) — dependent on CPU with integrated graphics.
-
USB Ports: Includes USB 2.0, USB 5Gbps (Type-A), USB 10Gbps (Type-A), and USB 5Gbps (Type-C).
-
Form Factor: micro-ATX (243.84 x 243.84 mm).
