CPU & Chipset
-
Socket: LGA1851
-
Supported CPUs: Intel Core Ultra (Series 2)
-
Chipset: Intel Z890
Memory
-
Slots: 4 x DDR5 DIMM
-
Max Capacity: 256 GB
-
Speed: Up to 8800 MT/s (OC), supports XMP
-
Supports: ECC (non-ECC mode), dual-channel
Graphics & Audio
-
Integrated Graphics: Intel HD (via CPU)
-
Ports: 1 x DisplayPort 2.1, 1 x USB4 Type-C (40 Gbps, DP Alt Mode)
-
Audio: Realtek ALC897, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 5.0 x16 (CPU), 2 x PCIe 4.0 x4 (chipset), 1 x PCIe 4.0 x1
-
M.2: 3 x M.2 (1 x PCIe 5.0 x4, 2 x PCIe 4.0 x4)
-
SATA: 4 x SATA III (6 Gb/s), RAID 0/1/5/10
Connectivity
-
Wi-Fi & Bluetooth: Wi-Fi 6E (802.11ax), Bluetooth 5.3
-
LAN: Realtek 2.5GbE
-
USB:
-
Back: 1 x USB4 Type-C, 4 x USB 3.2 Gen 1, 1 x USB 3.2 Gen 2, 4 x USB 2.0
-
Internal: 1 x USB 3.2 Gen 1 Type-C, 2 x USB 3.2 Gen 1, 4 x USB 2.0 headers
-
Power & Form Factor
-
Form Factor: ATX (30.5 × 24.4 cm)
-
Power Connectors: 24-pin ATX, 8+8-pin EPS
-
VRM: 12+1+2 Phase Hybrid VRM
-
Cooling: Passive heatsinks, M.2 Thermal Guard
-
RGB Headers: 3 x Addressable Gen2, 1 x RGB
-
Features: Q-Flash Plus, EZ-Latch, Clear CMOS, 2 x Thunderbolt add-in card headers
