CPU & Chipset
-
Socket: AM5
-
Supported CPUs: AMD Ryzen 9000, 8000, 7000 Series
-
Chipset: AMD X870
Memory
-
Slots: 4 x DDR5 DIMM
-
Max Capacity: 256 GB
-
Speed: Up to 8000 MT/s (OC)
-
Supports: AMD EXPO
Graphics & Audio
-
Integrated Graphics: AMD Radeon (via CPU)
-
Ports: 1 x HDMI, 2 x USB4 Type-C (DP-Alt)
-
Audio: Realtek ALC1220, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 5.0 x16 (UD Slot X), 1 x PCIe 4.0 x4, 1 x PCIe 3.0 x2
-
M.2: 4 x M.2 (3 x PCIe 5.0 x4, 1 x PCIe 4.0 x4)
-
SATA: 4 x SATA III
Connectivity
-
Wi-Fi & Bluetooth: Wi-Fi 7, Bluetooth 5.4
-
LAN: 2.5GbE
-
USB:
-
Back: 2 x USB 3.2 Gen 2, 4 x USB 3.2 Gen 1, 4 x USB 2.0, 2 x USB4 Type-C
-
Internal: 1 x USB-C 20Gbps, 2 x USB 3.2 Gen 1, 4 x USB 2.0 headers
-
Power & Form Factor
-
Form Factor: ATX (12.0″ x 9.6″)
-
Power Connectors: 24-pin ATX, 8+8-pin EPS
-
VRM: 16+2+2 Phase Digital VRM
-
Cooling: VRM Thermal Armor Advanced, M.2 Thermal Guard L
-
Features: EZ-Latch Plus (PCIe/M.2), WIFI EZ-Plug, Q-Flash Plus
