CPU & Chipset
-
Socket: LGA1851
-
Supported CPUs: Intel Core Ultra (Series 2)
-
Chipset: Intel H810
Memory
-
Slots: 2 x DDR5 DIMM
-
Max Capacity: 128 GB
-
Speed: Up to 6400 MT/s, supports XMP
-
Supports: ECC (non-ECC mode), dual-channel
Graphics & Audio
-
Integrated Graphics: Intel HD (via CPU)
-
Ports: 1 x HDMI 2.1 (4096×2160@60 Hz), 1 x D-Sub
-
Audio: Realtek ALC897, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 4.0 x16, 1 x PCIe 3.0 x1
-
M.2: 1 x PCIe 4.0 x4 (2280, M key)
-
SATA: 4 x SATA III (6 Gb/s), RAID 0/1/5/10
Connectivity
-
LAN: Realtek GbE (1 Gbps)
-
USB:
-
Back: 1 x USB 3.2 Gen 1, 5 x USB 2.0
-
Internal: 1 x USB 3.2 Gen 1, 2 x USB 2.0
-
Power & Form Factor
-
Form Factor: Micro ATX (22.6 × 18.5 cm)
-
Power Connectors: 24-pin ATX, 8-pin EPS
-
VRM: 4+1+2 Hybrid Digital VRM
-
Features: PCIe EZ-Latch, Q-Flash Plus, Smart Fan 6
