CPU & Chipset
-
Socket: LGA1851
-
Supported CPUs: Intel Core Ultra 200 Series
-
Chipset: Intel B860
Memory
-
Slots: 4 x DDR5 DIMM
-
Max Capacity: 256 GB
-
Speed: Up to 9200 MT/s (OC), supports XMP
-
Supports: Dual-channel, ECC (non-ECC mode)
Graphics & Audio
-
Integrated Graphics: Intel HD (via CPU)
-
Ports: 1 x HDMI, 1 x DisplayPort, 1 x USB4 Type-C (DisplayPort Alt Mode)
-
Audio: Realtek ALC897, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 5.0 x16, 1 x PCIe 4.0 x4
-
M.2: 2 x M.2 (1 x PCIe 5.0 x4, 1 x PCIe 4.0 x4)
-
SATA: 4 x SATA III (6 Gb/s), RAID 0/1/5/10
Connectivity
-
Wi-Fi & Bluetooth: Wi-Fi 6E (802.11ax), Bluetooth 5.3
-
LAN: 2.5GbE
-
USB:
-
Back: 1 x USB4 Type-C, 3 x USB 3.2 Gen 1, 5 x USB 2.0
-
Internal: 1 x USB 3.2 Gen 1 Type-C, 2 x USB 3.2 Gen 1, 4 x USB 2.0 headers
-
Power & Form Factor
-
Form Factor: Micro ATX (9.6″ × 9.6″)
-
Power Connectors: 24-pin ATX, 8-pin EPS
-
VRM: 8+1+2+2 Phase Hybrid VRM
-
Cooling: VRM Thermal Armor, M.2 Thermal Guard
-
RGB Headers: 4 x RGB LED
-
Features: EZ-Latch Plus, Q-Flash Plus, Thunderbolt header support
