CPU & Chipset
-
Socket: LGA1851
-
Supported CPUs: Intel Core Ultra (Series 2)
-
Chipset: Intel B860
Memory
-
Slots: 4 x DDR5 DIMM
-
Max Capacity: 256 GB
-
Speed: Up to 9066 MHz (OC), supports XMP
-
Supports: Dual-channel, ECC (non-ECC mode)
Graphics & Audio
-
Integrated Graphics: Intel HD (via CPU)
-
Ports: 1 x HDMI 2.1, 2 x DisplayPort 2.1
-
Audio: Realtek ALC897, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 5.0 x16 (UD Slot), 3 x PCIe 4.0 x1
-
M.2: 2 x M.2 (1 x PCIe 5.0 x4, 1 x PCIe 4.0 x4)
-
SATA: 4 x SATA III (6 Gb/s), RAID 0/1/5/10
Connectivity
-
Wi-Fi & Bluetooth: Wi-Fi 6E (802.11ax), Bluetooth 5.3
-
LAN: 2.5GbE (Realtek)
-
USB:
-
Back: 1 x USB 3.2 Gen 2 Type-A, 2 x USB 3.2 Gen 1, 3 x USB 2.0
-
Internal: 1 x USB 3.2 Gen 1 Type-C, 1 x USB 3.2 Gen 1, 2 x USB 2.0 headers
-
Power & Form Factor
-
Form Factor: Micro ATX (24.4 × 24.4 cm)
-
Power Connectors: 24-pin ATX, 8-pin EPS
-
VRM: 8+1+2+2 Phase Hybrid VRM
-
Cooling: VRM Heatsink, M.2 Thermal Guard
-
RGB Headers: 3 x Addressable LED, 1 x RGB LED
-
Features: Q-Flash Plus, EZ-Latch Plus/Click, WIFI EZ-Plug
