CPU & Chipset
-
Socket: AM5
-
Supported CPUs: AMD Ryzen 9000, 8000, 7000 Series
-
Chipset: AMD B850
Memory
-
Slots: 4 x DDR5 DIMM
-
Max Capacity: 256 GB
-
Speed: Up to 8200 MT/s (OC)
-
Supports: AMD EXPO and Intel XMP
Graphics & Audio
-
Integrated Graphics: AMD Radeon (via CPU)
-
Ports: 1 x HDMI 2.1 (4096×2160@60 Hz), 1 x DisplayPort 1.4 (3840×2160@144 Hz)
-
Audio: Realtek Audio CODEC, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 5.0 x16 (CPU), 3 x PCIe 3.0 x1 (chipset)
-
M.2: 3 x M.2 (1 x PCIe 5.0 x4, 2 x PCIe 4.0 x4)
-
SATA: 4 x SATA III (6 Gb/s), RAID 0/1/5/10
Connectivity
-
Wi-Fi & Bluetooth: Wi-Fi 6 (802.11ax), Bluetooth 5.3
-
LAN: Realtek GbE (1 Gbps)
-
USB:
-
Back: 1 x USB-C 3.2 Gen1, 2 x USB 3.2 Gen2 (red), 2 x USB 3.2 Gen1, 4 x USB 2.0
-
Internal: 1 x USB-C, 2 x USB 3.2 Gen1, 4 x USB 2.0 headers
-
Power & Form Factor
-
Form Factor: ATX (30.5 × 24.4 cm)
-
Power Connectors: 24-pin ATX, 8-pin + 4-pin EPS
-
VRM: 6+2+2 Phase Digital VRM
-
Fan Headers: 5 total (Smart Fan 6)
-
RGB Headers: 3 x Addressable Gen2 LED, 1 x RGB LED
-
BIOS: 256 Mbit UEFI, supports Q-Flash Plus
