CPU & Chipset
-
Socket: LGA1700
-
Supported CPUs: 14th, 13th, and 12th Gen Intel Core, Pentium Gold, Celeron
-
Chipset: Intel B760
Memory
-
Slots: 4 x DDR5 DIMM
-
Max Capacity: 256 GB (64 GB per DIMM)
-
Speed: Up to 7600 MT/s (OC), supports XMP
-
Supports: ECC (non-ECC mode), dual-channel
Graphics & Audio
-
Integrated Graphics: Intel HD (via CPU)
-
Ports: 1 x D-Sub, 1 x HDMI 2.1 (4096×2160@60 Hz), 1 x DisplayPort 1.2 (4096×2304@60 Hz)
-
Audio: Realtek Audio CODEC, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 4.0 x16 (EZ-Latch), 2 x PCIe 3.0 x1
-
M.2: 2 x PCIe 4.0 x4 (2280/22110)
-
SATA: 4 x SATA III (6 Gb/s), RAID 0/1/5/10
Connectivity
-
LAN: Realtek GbE (1 Gbps)
-
USB:
-
Back: 3 x USB 3.2 Gen 1, 2 x USB 2.0
-
Internal: 1 x USB 3.2 Gen 1 Type-C, 2 x USB 3.2 Gen 1, 4 x USB 2.0
-
Power & Form Factor
-
Form Factor: Micro ATX (24.4 × 24.4 cm)
-
Power Connectors: 24-pin ATX, 8-pin EPS
-
VRM: 4+1+1 Hybrid Digital VRM
-
Features: Q-Flash Plus (BIOS update without CPU/GPU), Smart Fan 6 with FAN STOP
