CPU & Chipset
-
Socket: AM4
-
Supported CPUs: AMD Ryzen 5000 G-Series, Ryzen 5000, Ryzen 4000 G-Series, Ryzen 3000 G-Series, Ryzen 3000
-
Chipset: AMD B550
Memory
-
Slots: 4 x DDR4 DIMM
-
Max Capacity: 128 GB
-
Speed: Up to 4733 MT/s (OC), supports XMP and AMD EXPO
-
Supports: ECC and non-ECC unbuffered modules
Graphics & Audio
-
Integrated Graphics: AMD Radeon (via CPU)
-
Ports: 1 x HDMI 2.1 (4096×2160@60 Hz), 1 x DisplayPort 1.4 (5120×2880@60 Hz)
-
Audio: Realtek ALC1220, 7.1-channel HD Audio
Expansion & Storage
-
PCIe Slots: 1 x PCIe 4.0 x16 (CPU), 1 x PCIe 3.0 x16 (chipset), 1 x PCIe 3.0 x1
-
M.2: 2 x PCIe 4.0/3.0 x4 (2280/22110)
-
SATA: 4 x SATA III (6 Gb/s), supports RAID 0/1/10
Connectivity
-
Wi-Fi & Bluetooth: Realtek Wi-Fi 5 (802.11ac), Bluetooth 5.0
-
LAN: Realtek GbE (1 Gbps)
-
USB:
-
Back: 4 x USB 3.2 Gen 1, 2 x USB 2.0, 1 x USB-C (Gen 1)
-
Internal: 1 x USB 3.2 Gen 1, 2 x USB 2.0 headers
-
Power & Form Factor
-
Form Factor: Micro ATX (24.4 × 24.4 cm)
-
Power Connectors: 24-pin ATX, 8-pin EPS
-
VRM: 5+3 Phase Digital VRM
-
Fan Headers: 3 total (Smart Fan 5)
-
RGB Headers: 2 x RGB, 2 x Addressable LED
-
BIOS: UEFI with Q-Flash Plus (update without CPU/GPU)
-
Release Date: July 2025
