Storage

• M.2 Slots (5):

  • 1 x PCIe 5.0 x4 (22110/2280/2260/2242)

  • 4 x PCIe 4.0 x4 (2280/22110), one supports SATA

• SATA Ports: 4 x 6 Gb/s

• RAID Support: RAID 0/1/5/10

Expansion Slots

• 1 x PCIe 5.0 x16 (SafeSlot, CPU-connected)

• 1 x PCIe 4.0 x16 (x4 mode, chipset-connected)

Networking & Wireless

• Wi-Fi: Wi-Fi 7 (802.11be) with ASUS Q-Antenna

• Bluetooth: v5.4

• Ethernet: Intel I226-V 2.5Gb LAN

USB Ports

• Rear I/O (14 ports):

  • 2 x Thunderbolt™ 4 (USB Type-C)

  • 1 x USB 20Gbps (Type-C)

  • 4 x USB 10Gbps (Type-A)

  • 1 x USB 10Gbps (Type-C with 30W PD fast charge)

  • 4 x USB 5Gbps (Type-A)

  • 2 x USB 2.0 (Type-A)

• Internal Headers:

  • 1 x USB 20Gbps (Type-C front panel)

  • 2 x USB 5Gbps (supports 4 ports)

  • 4 x USB 2.0 (supports 6 ports)

Audio

• Codec: Realtek ALC4080 with Savitech SV3H712 AMP

• Features: 120dB SNR output, 110dB SNR input, Dolby Atmos, SupremeFX Shielding

• Outputs: 7.1 Surround, optical S/PDIF, 2 gold-plated jacks

Cooling & Headers

• Fan Headers: 5 x 4-pin PWM (CPU + 4 chassis)

• Pump Header: 1 x 4-pin AIO

• RGB: 3 x Addressable Gen 2 headers

• Cooling Design: VRM heatsink array, 4x M.2 heatsinks, chipset heatsink, heat pipe integration

Additional Features

• AI Technologies: AI Overclocking, AI Cooling II, AI Networking II, NPU Boost (up to 24% NPU OC)

• Connectivity: HDMI 2.1, DisplayPort 2.1

• DIY Design: M.2 Q-Latch, SafeSlot, Polymo Lighting, Q-Release

• ASUS AI Advisor: AI-powered support via natural language
