Memory

• Memory Type: DDR4

• Memory Slots: 2 x DIMM

• Max Capacity: 64GB

• Memory Speed: Up to 3200 MHz (supports XMP)

• Channels: Dual-channel

Expansion Slots

• PCIe 4.0 x16: 1 slot (SafeSlot Core)

• PCIe 3.0 x1: 1 slot

Storage

• M.2 Slots: 2

  • M.2_1: 2242/2260/2280, PCIe 3.0 x4

  • M.2_2: 2242/2260/2280, PCIe 3.0 x2

• SATA III Ports: 4

Rear I/O Ports

• USB:

  • 2 x USB 3.2 Gen 2 (Type-A)

  • 4 x USB 2.0 (Type-A)

• Video:

  • 1 x HDMI (supports 4K@60Hz)

  • 1 x DisplayPort 1.4 (supports 4K@60Hz)

  • 1 x D-Sub (VGA)

• Audio: 3 x 3.5mm jacks (7.1 surround sound)

• Network: 1 x Intel 1Gb Ethernet

• Others: 1 x PS/2 (keyboard), 1 x PS/2 (mouse), V-M.2 (Key E) for Wi-Fi

Internal Connectors

• USB Headers:

  • 1 x USB 3.2 Gen 1 (supports 2 ports)

  • 2 x USB 2.0 (supports 3 ports)

• Fan Headers:

  • 1 x 4-pin CPU fan

  • 2 x 4-pin chassis fan

• RGB Headers:

  • 2 x AURA RGB

  • 3 x Addressable Gen 2

• Others: TPM header, COM port, S/PDIF out, front panel audio, clear CMOS

Power and Cooling

• Power Connectors: 1 x 24-pin ATX, 1 x 8-pin EPS

• Cooling Features: VRM heatsink, Fan Xpert 2+

Software and Features

• Software: Armoury Crate, AI Suite 3, UEFI BIOS

• Protections: ASUS 5X Protection III (DIGI+ VRM, LANGuard, SafeSlot Core, etc.)

• AURA Sync: Full RGB lighting control and synchronization
