Core Specifications
-
Socket: AMD AM5 (supports Ryzen 9000, 8000, and 7000 Series Desktop Processors)
-
Chipset: AMD B840
-
Form Factor: ATX (12.0″ x 9.6″)
-
Memory: 4 x DDR5 DIMM slots, dual-channel, supports up to 7600+ MT/s (OC), EXPO™ and AEMP support
-
Power Design: 8+2+1 phase digital VRM with 6-layer PCB for enhanced stability and overclocking
-
Warranty: 3 years (ASUS Corporate Stable Model – CSM with 36-month lifecycle support)
Storage & Expansion
-
M.2 Slots: 3 total
-
M.2_1: PCIe 4.0 x4 (2280)
-
M.2_2: PCIe 4.0 x4 (2280)
-
M.2_3: PCIe 3.0 x4 (2242/2260/2280)
-
-
SATA: 4 x SATA 6Gb/s ports
-
PCIe Slots:
-
1 x PCIe 4.0 x16 (x16 mode)
-
1 x PCIe 3.0 x16 (x4 mode)
-
2 x PCIe 3.0 x16 (x1 mode)
-
1 x PCIe 3.0 x1
-
Connectivity & Networking
-
Wi-Fi: Wi-Fi 6E (802.11ax, 2×2), supports 2.4/5/6 GHz bands
-
Bluetooth: v5.3
-
Ethernet: 1 x Realtek 2.5Gb LAN
-
Rear I/O Ports:
-
1 x USB 10Gbps (Type-C)
-
1 x USB 10Gbps (Type-A)
-
2 x USB 5Gbps (Type-A)
-
4 x USB 2.0 (Type-A)
-
1 x DisplayPort 1.4 (up to 8K@30Hz)
-
1 x HDMI 2.1 (up to 4K@60Hz)
-
3 x Audio jacks
-
1 x BIOS FlashBack™ button
-
-
Internal Headers:
-
1 x USB 5Gbps (Type-C)
-
1 x USB 5Gbps header (2 ports)
-
2 x USB 2.0 headers (4 ports)
-
1 x Thunderbolt™ (USB4®) header
-
Cooling & Management
-
Fan Headers:
-
1 x 4-pin CPU fan
-
1 x 4-pin CPU OPT fan
-
1 x 4-pin AIO pump
-
4 x 4-pin chassis fans
-
-
Heatsinks: VRM, M.2, and PCH heatsinks with thermal pads
-
Cooling Tech: Fan Xpert 2+, hybrid PWM/DC fan control, multiple temperature sources
AI & Software Features
-
AI Ready: Optimized for AI workloads with AI Cache Boost (up to 29% faster LLM performance)
-
AI Advisor: Onboard BIOS assistant for tuning and diagnostics
-
Aura Sync RGB: 3 x Addressable Gen 2 headers for customizable lighting
-
ASUS Control Center Express: IT management software for enterprise environments
