Core Specifications
-
Model: GV-N166SOC-6GD (OC model)
-
GPU Chipset: NVIDIA GeForce GTX 1660 SUPER
-
Architecture: NVIDIA Turing
-
CUDA Cores: 1408
-
Base Clock: 1530 MHz
-
Boost Clock: 1830 MHz (OC model), up to 1860 MHz on GAMING OC variants
-
TDP: 125 W
-
Recommended PSU: 450 W
-
Power Connector: 1 x 8-pin PCIe
Memory
-
Memory Size: 6 GB
-
Memory Type: GDDR6
-
Memory Interface: 192-bit
-
Memory Speed: 14 Gbps (14000 MHz)
-
Memory Bandwidth: 336 GB/s
Cooling & Design
-
Cooling System: WINDFORCE 2X (dual fans) for standard OC model
-
Fan Design: 90mm unique blade fans with alternate spinning
-
Back Plate: Reinforced protection back plate
-
Form Factor: Dual-slot, ATX
-
Dimensions: 225.65 x 122.02 x 40.5 mm (LxWxH)
Display Outputs
-
DisplayPort: 3 x DP 1.4
-
HDMI: 1 x HDMI 2.0b
-
Max Resolution: 7680 x 4320 @ 60 Hz
-
Multi-View Support: Up to 4 displays
Additional Features
-
API Support: DirectX 12, OpenGL 4.6
-
Technologies: NVIDIA G-SYNC support, GeForce Experience
-
Software Control: RGB Fusion 2.0 (on GAMING OC models for RGB lighting
