GPU & Performance

• GPU: NVIDIA® GeForce RTX™ 5070 (Blackwell Architecture)

• CUDA Cores: 6144 Units

• Core Clock:

  • Boost: 2542 MHz (GAMING & SILENT Mode)

  • Extreme Performance: 2557 MHz (OC Mode via MSI Center)

• AI Performance: 988 TOPS (Dedicated AI Cores)

Memory

• VRAM: 12GB GDDR7

• Memory Speed: 28 Gbps

• Memory Bus: 192-bit

• Memory Bandwidth: ~672 GB/s (calculated)

Power & Cooling

• Power Consumption: 250 W

• Recommended PSU: 650 W

• Power Connector: 1x 16-pin (ATX 3.1 recommended)

• Cooling: Dual TORX 5.0 Fans with ZERO FROZR (0 RPM mode)

• Cooler Design: Nickel-plated copper base, full-length heat pipes, thermal pads

Outputs & Connectivity

• DisplayPort: 3x DisplayPort 2.1b

• HDMI: 1x HDMI 2.1b (supports up to 4K@480Hz or 8K@120Hz with DSC)

• Max Resolution: 7680 x 4320 (8K)

• Multi-Display Support: Up to 4 displays

• G-SYNC® Support: Yes

• VR Ready: Yes

Physical & Other

• Dimensions: 236 x 126 x 50 mm (9.29″ x 4.96″ x 1.97″)

• Slot Width: 2.5 slots

• Weight: 774 g (card only)

• Interface: PCI Express 5.0 x16

• Warranty: 3 Years

• Model Number: G5070-12V2C (Black), G5070-12V2CW (White)
