Core Specifications

• GPU: NVIDIA GeForce RTX 5070 (Blackwell architecture, GB205-300-A1, 5 nm)

• CUDA Cores: 6,144 (48 SMs)

• Boost Clock: 2,542 MHz

• Extreme Performance Clock: 2,557 MHz (via MSI Center)

• FP32 Compute Performance: ≈ 31 TFLOPS

Memory & Bandwidth

• VRAM: 12 GB GDDR7

• Memory Interface: 192-bit

• Memory Speed: 28 Gbps

• Bandwidth: ~672 GB/s

Power & Cooling

• TDP: 250 W

• Power Connector: 1 × 16-pin (ATX 3.1 recommended)

• Recommended PSU: 650 W

• Cooling: Dual Torx Fan 5.0, Zero Frozr (0 dB idle), nickel-plated copper baseplate, Core Pipes, reinforcing backplate with airflow vent

Outputs & Resolution

• Display Outputs: 3 × DisplayPort 2.1b, 1 × HDMI 2.1b

• Max Resolution: 7680 × 4320 (8K @ 120 Hz with DSC)

• Max Displays Supported: 4

• G-SYNC Support: Yes

Design & Dimensions

• Form Factor: Compact dual-fan design

• Dimensions: 231 × 126 × 50 mm

• Weight: 724 g (card), 1,107 g (packaged)

• Slot Width: 2.2-slot

Features & Compatibility

• APIs: DirectX 12 Ultimate, OpenGL 4.6

• Technologies: DLSS 4 (Multi-Frame Generation), 4th-gen RT Cores, Reflex 2, AV1/H.264/HEVC encode-decode

• Software: MSI Center, Afterburner support

• Warranty: 3 years
