TUF-RX9070XT-O16G-GAMING
Graphic Engine
AMD Radeon™ RX 9070 XT
Engine Clock
OC mode(GPU Tweak III): up to 3080 MHz (Boost Clock)/up to 2540 MHz (Game Clock)
Default mode: up to 3060 MHz (Boost Clock)/up to 2520 MHz (Game Clock)
OC mode(GPU Tweak III): up to 3080 MHz (Boost Clock)/up to 2540 MHz (Game Clock)
Default mode: up to 3060 MHz (Boost Clock)/up to 2520 MHz (Game Clock)
Default mode: up to 3060 MHz (Boost Clock)/up to 2520 MHz (Game Clock)
OC mode(GPU Tweak III): up to 3080 MHz (Boost Clock)/up to 2540 MHz (Game Clock)
Default mode: up to 3060 MHz (Boost Clock)/up to 2520 MHz (Game Clock)
Memory Speed
20 Gbps
Interface
Yes x 1 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1a)
HDCP Support Yes (2.3)
Yes x 3 (Native DisplayPort 2.1a)
HDCP Support Yes (2.3)
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
16GB GDDR6
Stream Processors
4096
Memory Interface
256-bit
Resolution
Digital Max Resolution 7680 x 4320
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x TUF certificate of Reliability
1 x TUF Gaming Graphics Card Holder
1 x TUF Velcro Hook & Loop
1 x TUF Fridge Magnet
1 x Thank you card
1 x Speedsetup Manual
1 x TUF Gaming Graphics Card Holder
1 x TUF Velcro Hook & Loop
1 x TUF Fridge Magnet
1 x Thank you card
1 x Speedsetup Manual
Software
ASUS GPU Tweak III & Drivers: please download all software from the support site.
Dimensions
330 x 140 x 62.5 mm
13 x 5.5 x 2.5 inch
13 x 5.5 x 2.5 inch
Recommended PSU
850W
Power Connectors
3 x 8-pin
Slot
3.125 Slot
AURA SYNC
RGB
